220V Automatic Screw Capping Machine Customized PLC Control System

Large Image : 220V Automatic Screw Capping Machine Customized PLC Control System

Product Details:

Place of Origin:	China
Brand Name:	SENCAN
Certification:	CE
Model Number:	SC-PT-03

Payment & Shipping Terms:

Minimum Order Quantity:	1
Packaging Details:	Wooden case
Delivery Time:	90 Working days
Payment Terms:	L/C, T/T
Supply Ability:	3 sets per month

Contact Now

Detailed Product Description

Frequency:	50Hz	Safety Features:	Emergency Stop Button, Safety Door Switch
Capacity:	4500-22000 Per/hour	Material:	Stainless Steel + Aluminium Alloy
Power Source:	Electric	Voltage:	220V
Screwing Speed:	Adjustable	Control System:	PLC
Highlight:	220V Automatic Screw Capping Machine , Automatic Screw Capping Machine Customized , PLC Control Screw Capping Machine

Cap Screwing Machines

1. Customize rotary or loop type machine for customer’s capacity requirements.

2. Main power from servo motor + reducer unit, which provide intermittent motion and fixtures are in a static during assembling, high accuracy and qualified rate can be achieved.

3. Screw in place precisely, no twist angle and twist broken occur.

4. Does not destroy appearance of product, high qualified rate performed.

5. Option screw force detector for torque requirements.

6. Detection after each assembly process, 100% real qualified products.

7. All part made of stainless steel or aluminum alloy, in accordance with GMP requirements.

8. PLC control system, touch screen HMI operation.

9. Simple maintenance easy operation. No high technical requirement for operator.

10. Easy maintenance of spare parts, short time replacement.

Properties

Applicable products	Parts require scew fasten
Production speed	2500-10000pcs/hr (according to customer’s requirement)
Rate of qualified product	Above 98%(depend on semi-product quality)
Rate of operation rate	Above 95%
Power source	AC380V, 50Hz, 3kw/hr
dimension	Varied with different product and output
weight	About 1500kg
operator	1set/person
