Disinfection Cap Automatic Bottle Capping Machine Stainless Steel Material OEM

Brand Name:	Sencan
Model Number:	SC-PT-534
MOQ:	1 set
Price:	Deliberation
Payment Terms:	T/T
Supply Ability:	3 sets per

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Material:

Stainless Steel + Aluminium Alloy

Application:

Medical Cap Assembly

Power Supply:

220V/380V

Control System:

PLC

Safety Features:

Emergency Stop Button, Safety Guards

Product Type:

Assembly Machine

Warranty:

1 Year

Capacity:

4500-22000 Per/hour

Packaging Details:

wooden case

Highlight:

OEM Automatic Bottle Capping Machine

Disinfection Cap Automatic Bottle Capping Machine

Stainless Steel Automatic Capping Machine

Product Description

Stainless Steel Medical Product Assembly Machine For Iodophor Cap And Disinfection Cap

Features

1. Used for automatic assembly of iodophor cap for peritoneal dialysis external extension tube end, infection cap for infusion connector and catheter.

2. Customized rotary or loop line turntable type machine according to customers' actual capacity.

3. Each assembly process is equipped with detection to ensure high quality qualified products.

4. Accuracy of iodine/disinfectant liquid adding can be controlled within 0.005ml.

5. High sponge loading precision, 1/3 of the upper surface can be flat.

6. Automatically welding aluminum foil or assemble caps for sealing option (according to customer requirements). Alu foil in rolls can be cut automatically inline, or ready cut foil being welded directly.

7. Machine made of stainless steel and aluminum alloy, in accordance with GMP requirements.

8. Main power from servo motor + reducer, induce intermittent motion which make fixtures in static status during assembly, provide high rate of qualified product.

9. PLC control system, touch screen HMI operation.

10. Can be connected with pouch packaging machine to form automatic production line.

Properties

Applicable products	Iodine mini cap, iodophor cap, disinfection cap
Production speed	1200-10000pph (according to customer’s requirement)
Rate of qualified product	Above 98%(dependent on semi-product quality)
Rate of operation rate	Above 95%
Power source	AC380V, 50Hz, 4kw; air pressure: 7kg/m3
Dimension	Actual size varied with different production speed
Weight	About 1850kg
Operator	1set/person
