OEM Safety Lancet Production Line PLC Control Medical Injection Molding Machine

Large Image : OEM Safety Lancet Production Line PLC Control Medical Injection Molding Machine

Product Details:

Place of Origin:	China
Brand Name:	Sencan
Certification:	CE
Model Number:	SC-P541

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Deliberation
Packaging Details:	wooden case
Delivery Time:	90 work days
Payment Terms:	T/T
Supply Ability:	3 sets per

Contact Now

Detailed Product Description

After-Sales Service:	Online Support, Field Installation, Commissioning And Training	Material:	Stainless Steel + Aluminium Alloy
Warranty:	1 Year	Control System:	PLC Control
Safety Features:	Automatic Safety Lock	Production Capacity:	4500-25000 Units Per Hour
Power Supply:	220V/50Hz
Highlight:	OEM Safety Lancet Production Line , OEM Medical Injection Molding Machine , PLC Control Medical Injection Molding Machine

Safety Lancet Production Line AC380V Power Source And 98% Rate Of Qualified Product

Features

1. An automated setup for the blood collection needles and lancet.
2. A production-specific rotating turntable or loop line.
3. The indexing drive and main power servo motor provide precise assembly position and excellent accuracy.
4. To guarantee a high certified rate of assembled items, a detecting function follows each assembly process.
5. Features an automated reset mechanism and a lancet ejector for a high rate of qualified goods.

6. The use of pneumatic power shortens the time needed for equipment replacement and maintenance and eliminates the need for highly skilled and technical personnel.
7. Every driving and inspection element is sourced from vendors worldwide.
8. GMP-compliant machine components composed of aluminum alloy and stainless steel.
9. HMI operation and PLC control system.

Properties

Applicable products	Peripheral blood collecting needles, blood lancet, adjustable lancet, safety lancet
Production speed	2500-8000pph
Rate of qualified product	Above 98%
Rate of operation rate	Above 95%
Power source	AC380V, 50Hz,3kw/h, air pressure 7kg/m3
Dimension	Actual size varied with production speed
Weight	About 2850kg
Operator	1set/person
