Stainless Steel Euro Cap Assembly Machine For IV Infusion Bags And Bottles And Customizable

Brand Name:	Sencan
Model Number:	SC-PT-626
MOQ:	1 set
Price:	Deliberation
Payment Terms:	T/T, L/C
Supply Ability:	3 sets per

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Product Type:

Assembly Machine

Power Supply:

380V/50Hz

Control System:

PLC

Capacity:

High

Production Efficiency:

High

Voltage:

220V

Type:

Assembly Machine

Accuracy:

High

Cap Type:

Euro-cap

Packaging Details:

wooden case

Highlight:

Stainless Steel Euro Cap Assembly Machine

Customizable Euro Cap Assembly Machine

Product Description

Characteristics
1.This machine is used for the automatic assembly of caps for plastic bags and bottles used for IV infusion.
2.Machine is made of stainless steel + aluminium alloy, in accordance with ISO and GMP standards.
3.Each work station has an independent power source, which is convenient for daily maintenance.
4. Product contact surface is polished for product protection.
5.The inner cap is pressed by servo-linked rod structure system, with uniform and stable pressure each position each work station, the press quality of each cap could be guaranteed.
6.Each assembling process is followed with checking function to make sure no defective products in qualified products.
7.PLC control, human-machine interface control. No high professional technical requirement for operator.
8.The main power is composed of servo motor + indexing drive, high assembly precision and qualified assembly rate.
9.Pneumatic power for shorter maintenance period
10.High degree of customization according to customer's requirements, actual capacity and production demand.

Properties

Applicable products	Loop pull cap, double pull cap, single fold closure, double fold cap, break caps
Production speed	3600-1400pcs/hr (according to customer’s requirement)
Rate of qualified product	Above 99%
Rate of operation rate	Above 95%
Power source	AC380V,50Hz,4kw/hr
Dimension	Actual size varied with different production speed
Weight	About 2300kg
Operator	3sets/2persons,recommend 1set/person
