Product Details:
Payment & Shipping Terms:
|
| Operator: | Single | Power Consumption: | 220V |
|---|---|---|---|
| Assembly Type: | Fully Automatic | Power Supply: | 220V/380V |
| Product_Name: | Daily Necessities Assembly Machine | Frequency: | 50Hz |
| Operation Mode: | Touch Screen | Control System: | PLC |
| Power_Source: | Electricity | Application: | Assembly Of Daily Necessities |
| Operating Interface: | Touch Screen | Control Panel: | Touch Screen |
| Assembly_Type: | Fully Automatic | Production Efficiency: | 99% |
| Applicable Products: | Food And Drug Cover | ||
| Highlight: | Customizable Jelly cap Assembly Machine |
||
Features
1.Round shaped caps will be loaded by feeding device which is stable and fast.
2.Each assembling process is well checked, to be sure 100% qualification of qualified products.
3.Equipped with automatic counting function for production statistics.
4.Qualified and unqualified products are released from separate exits.
5.Main drive from servo motor + indexing drive, with stable running speed and high assembly accuracy.
6.PLC control system and touch screen, easy operation for operators
7.Customized according to customer's specifications and capacity requirements.
Properties
| Applicable products | Jelly cap |
| Production speed | Depend on moulding cavity quantity |
| Rate of qualified product | Above 99% |
| Rate of operation rate | Above 97% |
| Power source | AC380V, 50Hz,4kw/hr |
| Dimension | L1950×W1250×H1900(mm) Actual size varied |
| Weight | About 2800kg |
| Operator | 1set/person |
