Automatic Reset Function And High Qualified Rate For Customizable Safety Lancet Production Line

Brand Name:	Sencan
Model Number:	SC-PT-361
MOQ:	1 set
Price:	Deliberation
Payment Terms:	T/T, L/C
Supply Ability:	3 sets per

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Country Of Origin:

China

Production Capacity:

1000-12000units/hour

Qualified Rate:

99%

Automation Grade:

Semi-Automatic

Color:

Silvery

Control System:

PLC

Operation:

Touch Screen

Certification Apacity:

Application:

Safety Lancet Needle

Warranty:

1 Year

Material:

Stainless Steel

Operation Type:

Turntable

Power Supply:

220V, 50Hz

Operation Mode:

Intermittent

Packaging Details:

wooden case

Highlight:

Automatic Reset Safety Lancet Production Line

Customizable Safety Lancet Production Line

Product Description

Features

1. Automatic assembly for blood lancet, blood collecting needles.

2. Customized loop line or rotatory turntable for production.

3. Main power servo motor + indexing drive, which provide accurate assembly position and high quality accuracy.

4. Each assembly process is followed by detection function to ensure high qualified rate of assembly products

5. Equipped with lancet eject and automatic reset functions for high rate of qualified product.

6. Pneumatic power to reduce time of machine maintenance and replacement, no high professional and technical requirements for maintenance.

7. All driving and inspection parts come from international suppliers.

8. Machine materials made of stainless steel and aluminum alloy, in compliance with GMP requirements.

9. PLC control system, HMI operation.

Properties

Applicable products	Peripheral blood collecting needles, blood lancet, adjustable lancet, safety lancet
Production speed	2500-8000pph
Rate of qualified product	Above 98%
Rate of operation rate	Above 95%
Power source	AC380V, 50Hz,3kw/h, air pressure 7kg/m³
Dimension	Actual size varied with production speed
Weight	About 2850kg
Operator	1set/person
