Sport Cap Assembly Machine With Servo Motor And No High To Seperator

Brand Name:	SENCAN
Model Number:	SC-TP-675
MOQ:	1 set
Price:	Negotiate the price according to actual situation
Payment Terms:	T/T,L/C
Supply Ability:	3 sets

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, ISO9001

Control:

PLC

Applicable Product:

Sport Cap

Operation Method:

Touch Screen Control

Frequency:

50/60Hz

Cable Size:

Three-phase Five-wire System

Working Pressure:

0.5-0.8MPa

Bottle Height Range:

50-200mm

Assembly Method:

Automatic Feeding And Assembly

Qualified Rate:

99%

Power Source:

AC380V ,50Hz

Assembly Type:

Automatic

Production Efficiency:

99%

Assembly Speed:

4800-12000 Pieces/hour

Packaging Details:

Wooden case

Highlight:

Sport Cap Assembly Machine

Seperator Sport Cap Assembly Machine

Servo Motor Assembly Machine

Product Description

Features

1. Customize rotary or loop type machine for customer’s capacity requirements.

2. Main power from servo motor + reducer unit, which provide intermittent motion and fixtures are in a static during assembling, high accuracy and qualified rate can be achieved.

3. Screw in place precisely, no twist angle and twist broken occur.

4. Does not destroy appearance of product, high qualified rate performed.

5. Option screw force detector for torque requirements.

6. Detection after each assembly process, 100% real qualified products.

7. All part made of stainless steel or aluminum alloy, in accordance with GMP requirements.

8. PLC control system, touch screen HMI operation.

9. Simple maintenance easy operation. No high technical requirement for Operator.

10. Easy maintenance of spare parts, short time replacement.

11. Sport cap assembly machine+folding machine with cutting ring machine together

Properties

Applicable products	Sport cap, need to folding and cutting caps
Production speed	2500-10000pcs/hr (according to customer’s requirement)
Rate of qualified product	Above 98%(depend on semi-product quality)
Rate of operation rate	Above 95%
Power source	AC380V, 50Hz, 3kw/hr
Dimension	Varied with different product and output
Weight	About 1500kg
Operator	1set/person
