Euro Cap Assembly machine is applied for automatic assembly of caps for plastic IV infusion bags and bottles.

Brand Name:	SENCAN
Model Number:	SC-TP-703
MOQ:	1 set
Price:	Negotiate the price according to actual situation
Payment Terms:	T/T,L/C
Supply Ability:	3 sets

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ISO9001

Mechanism:

Servo

Applicable Products:

Euro Cap

Packing:

Wooden Case

Suitable Caps:

Euro-cap

Product Size:

Large

Configuration:

Inspection Machine

Operation:

About 95%

Model:

Cap Assembly Machine

Function:

Cap Assembly

Operating Interface:

Touch Screen

Application:

Cap Assembly For IV Bottles

Type:

Turntable

Main Drive:

Servo Motor And Indexing Disc

Product Type:

Assembly Machine

Warranty:

1 Year

Packaging Details:

Wooden case

Highlight:

Euro Cap Assembly machine for IV bags

automatic cap assembly machine

plastic IV bottle cap assembler

Product Description

Features

1. This machine is applied for automatic assembly of caps for plastic IV infusion bags and bottles.

2. Machine made of stainless steel + aluminum alloy, in compliance with ISO and GMP standards

3. Each workstation has independent driving source , convenient for daily maintenance.

4. The surface in contact with the product is polished to protect the product.

5. The inner cap is pressed by servo-linked rod structure system, with even and stable pressure each position each workstation, pressing quality of each cap could be guaranteed.

6. Each assemble process is followed with inspection function to make sure no defective products in qualified products.

7. PLC control system, human-machine interface operation. No high professional technical requirement for operator.

8. Main power composed of servo motor + indexing drive, high assembly precision and qualified rate.

9. Pneumatic power for shorter time of maintenance

10. Highly customized according to customer's requirements, actual capacity and production demand.

Properties

Applicable products	Loop pull cap, double pull cap, single fold closure, double fold cap, break caps
Production speed	3600-1400pcs/hr (according to customer’s requirement)
Rate of qualified product	Above 99%
Rate of operation rate	Above 95%
Power source	AC380V,50Hz,4kw/hr
Dimension	Actual size varied with different production speed
Weight	About 2300kg
Operator	3sets/2persons,recommend 1set/person
