Automatic Safety Lancet Production Line with 96% Operation Rate

Brand Name:	SENCAN
Model Number:	SC-TP-716
MOQ:	1 set
Price:	Negotiate the price according to actual situation
Payment Terms:	T/T,L/C
Supply Ability:	3-20 sets

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, ISO9001

Certifications:

CE, ISO 13485

Operation Rate:

96%

Safety Feature:

Needle Retracts Automatically After Use

Production Process:

Automatic Assembly

Processing Type:

Automatic

Active Force:

Servo Moter

Safety Features:

Safety Lock, Emergency Stop Button

Control:

PLC

Main Power:

Servo Moter

Automation Grade:

Automatic

Accuracy:

High

Applicable Products:

Blood Lancet Needle

Operating Interface:

Touch Screen

Packaging Details:

Wooden case

Highlight:

automatic safety lancet production line

safety lancet production line with warranty

high efficiency safety lancet production line

Product Description

Features

1. For picking placement and injection molding of products with needles like blood lancet, blood collecting needles.

2. Equipped with two needle hoppers, storage capacity 200,000 needles, available 24 hours’ production.

3. Assemble at an inclined angle to avoid needle tip damaging.

4. Binding and tightening device installed in needle hoppers to avoid chaos of needles.

5. Easy removed hopper lid, needles can be loaded within 3 minutes.

6. Production cycle 10-15s, high productivity and good stability.

7. New needle adsorption system (patented), not vacuumization mode, low electricity consumption.

8. Customized according to customer’s real capacity and requirements.

Properties

Applicable products	Pick and place needles then injection moulding for peripheral blood lancet, venous blood collecting needles, products with needles and injection moulding
Production speed	Depend on moulding cavity quantity
Rate of qualified product	Above 99%
Rate of operation rate	Above 97%
Power source	AC380V, 50Hz,4kw/hr
Dimension	L1950×W1250×H1900(mm) Actual size varied
Weight	About 2800kg
Operator	1set/person
