Product Details:
Payment & Shipping Terms:
|
| Type: | Automatic Bottle Packaging Machine | Bag Type: | Pillow Bag, Gusset Bag, Hanging Hole Bag |
|---|---|---|---|
| Port: | Shenzhen | Weight: | 800kg |
| Control: | PLC Or Double Drive | Speed: | 500-800pcs/h |
| Touch Screen: | 7 Inch Color Touch Screen | Control System: | PLC Control System |
| Highlight: | automatic bottle bagging machine with touch screen,high-speed bottle packaging machine 800pcs/h,industrial bottle bagging machine 7 inch display |
||
Features
1. Bag loading can be manually or automatically.
2. Automatic counting to prevent overloading or underloading during bagging process.
3. Can store a small amount of material, convenient for operator’s troubleshooting in a short period of time.
4. Can be connected to bottle blowing machine in-line, or stand alone (according to requirements of customers).
5. Conveyor belt and bagging equipment can be controlled separately, blowing equipment can keep production during maintenance stop of bagging machine.
6. PLC control system, touch screen HMI operation.
Properties
|
Applicable products |
All kinds of bottles one per bag or multiple in one bag |
|
Production speed |
according to blowing machine output and customer’s requirements |
|
Rate of qualified product |
Above 99% |
|
Rate of operation rate |
Above 95% |
|
Power source |
AC380V, 50Hz, 4kw/hr, compressed air:5kg/m3 |
|
Dimension |
Actual size varied with different production speed |
|
Weight |
About 1000kg |
|
Operator |
3set/person |
