Product Details:
Payment & Shipping Terms:
|
| Product Type: | Assembly Machine | Color: | Silver |
|---|---|---|---|
| Safety Protection: | Emergency Stop Button | Frequency: | 50/60Hz |
| Safety Features: | Multiple Safety Features | Mechanism: | Servo |
| Control Panel: | Touch Screen | Operation Interface: | Touch Screen |
| Product Certification: | CE, ISO9001 | Maintenance: | Easy Maintenance |
| Product Size: | Large | Control: | PLC |
| Voltage: | 220V | Satisfactory Rate: | About 99% |
| Highlight: | 220V Juice Cap Assembly Machine,50/60Hz Jelly Cap Assembly Machine,99% Satisfactory Rate Automatic Assembly Machine |
||
Features
1. Customize rotary or loop type machine for customer’s capacity requirements.
2. Main power from servo motor + reducer unit, which provide intermittent motion and fixtures are in a static during assembling, high accuracy and qualified rate can be achieved.
3. Screw in place precisely, no twist angle and twist broken occur.
4. Does not destroy appearance of product, high qualified rate performed.
5. Option screw force detector for torque requirements.
6. Detection after each assembly process, 100% real qualified products.
7. All part made of stainless steel or aluminum alloy, in accordance with GMP requirements.
8. PLC control system, touch screen HMI operation.
9. Simple maintenance easy operation. No high technical requirement for Operator.
10. Easy maintenance of spare parts, short time replacement.
Properties
|
Applicable products |
Parts require scew fasten assembling |
|
Production speed |
2500-10000pcs/hr (according to customer’s requirement) |
|
Rate of qualified product |
Above 98%(depend on semi-product quality) |
|
Rate of operation rate |
Above 95% |
|
Power source |
AC380V, 50Hz, 3kw/hr |
|
Dimension |
Varied with different product and output |
|
Weight |
About 1500kg |
|
Operator |
1set/person |
