Product Details:
Payment & Shipping Terms:
|
| Operating Mode: | Automatic | Size: | Customizable |
|---|---|---|---|
| Product Certification: | CE, ISO | Application: | Daily Necessities Production |
| Power Supply: | 220V/380V | Operating Rate: | 98% |
| Voltage: | 220V | Operation: | Touch Screen |
| Operation Mode: | Touch Screen | Operating Interface: | Touch Screen |
| Advantage: | Both Sizes Can Be Assembled Together | Safety Features: | Emergency Stop Button, Safety Sensors |
| Main Material: | Stainless Steel | Satisfactory Rate: | About 99% |
| Operating System: | PLC | ||
| Highlight: | 100% Inspection Jelly Cap Assembly Machine,Emergency Stop Button Laundry Detergent Cap Screwing Machine,Safety Sensors Daily Necessities Assembly Machine |
||
Features
1. Customize rotary or loop type machine for customer’s capacity requirements.
2. Main power from servo motor + reducer unit, which provide intermittent motion and fixtures are in a static during assembling, high accuracy and qualified rate can be achieved.
3. Screw in place precisely, no twist angle and twist broken occur.
4. Does not destroy appearance of product, high qualified rate performed.
5. Option screw force detector for torque requirements.
6. Detection after each assembly process, 100% real qualified products.
7. All part made of stainless steel or aluminum alloy, in accordance with GMP requirements.
8. PLC control system, touch screen HMI operation.
9. Simple maintenance easy operation. No high technical requirement for Operator.
10. Easy maintenance of spare parts, short time replacement.
Properties
|
Applicable products |
Parts require scew fasten assembling |
|
Production speed |
2500-10000pcs/hr (according to customer’s requirement) |
|
Rate of qualified product |
Above 98%(depend on semi-product quality) |
|
Rate of operation rate |
Above 95% |
|
Power source |
AC380V, 50Hz, 3kw/hr |
|
Dimension |
Varied with different product and output |
|
Weight |
About 1500kg |
|
Operator |
1set/person |
