High-Performance Euro Cap Assembly Machine for Fast and Accurate Assembly with 99% Satisfactory Rate and 4500-12000 per/hour Capacity

Large Image : High-Performance Euro Cap Assembly Machine for Fast and Accurate Assembly with 99% Satisfactory Rate and 4500-12000 per/hour Capacity

Product Details:

Place of Origin:	China
Brand Name:	SENCAN
Certification:	CE, ISO9001
Model Number:	SC-TP-814

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiate price according to actual situation
Packaging Details:	Wooden case
Delivery Time:	90 days
Payment Terms:	T/T,L/C
Supply Ability:	2-20 sets

Contact Now

Detailed Product Description

Air Pressure Gauge:	SMC	Operating Speed:	Adjustable
Operating Method:	Turntable/mechanical	Efficiency Ratio:	Above 95%
Operation Person:	1 Person	Material:	Stainless Steel
Product Power:	220V	Frequency:	50/60Hz
Assembly Capacity:	4500-12000 Per/hour	Operator:	Single
Satisfactory Rate:	About 99%	Applicable Caps:	Euro Caps
Operation Mode:	Semi-Automatic	Mechanism:	Servo
Highlight:	Fast and Accurate Euro Cap Assembly Machine , 99% Satisfactory Rate Infusion Cap Assembly Machine , 4500-12000 per/hour Automatic Cap Assembly Machine

High-Performance Euro Cap Assembly Machine for Fast and Accurate Assembly

Product Features

Designed for automatic assembly of easy peel foil caps for IV infusion soft bags and bottles
Constructed with stainless steel and aluminum alloy materials, compliant with GMP standards
Independent driving source for each workstation, facilitating easy maintenance
Product-contact surfaces polished for optimal product protection
Automated foil cutting and welding process
Integrated check function after each assembly step to ensure product quality
PLC control system with user-friendly interface, requiring minimal operator training
Servo motor + indexing drive power system for high precision assembly and qualification rates
Pneumatic power system reduces maintenance time and technical requirements
Fully customizable to meet specific product specifications, capacity, and production demands

Technical Specifications

Applicable Products	Peel seal foil caps, foil seal closures and lids
Production Speed	1500-8500pcs/hr (customizable to customer requirements)
Qualified Product Rate	Above 99%
Operation Rate	Above 95%
Power Source	AC380V, 50Hz, 4kw/hr
Dimensions	Varies according to production speed requirements
Weight	Approximately 2000kg
Operator Requirements	3 sets/2 persons, recommended 1 set/person
