Product Details:
Payment & Shipping Terms:
|
| Lighting Intensity: | Adjustable | Operating System: | Windows |
|---|---|---|---|
| Lighting Source: | LED | Application: | Industrial Inspection |
| Operation Rate: | 98% | Inspection Area: | 360 Degrees |
| Control System: | PLC | Main Power: | Servo Motor + Indexing Drive |
| Material: | Stainless Steel | Software: | Image Analysis System |
| Illumination: | LED | Display: | Touch Screen |
| Software Compatibility: | Windows, Mac, Linux | Connectivity: | USB, Ethernet |
| Qualified Rate: | 98% | ||
| Highlight: | PLC vision inspection machine,high operation rate inspection machine,video inspection machine with warranty |
||
Features
1. For products requiring appearance check, physical inspection, replace traditional artificial eyesight inspection.
2. False detection rate not exceed 0.3%.
3. Inspection scope: insufficient injection molding (lack of material), injection deformation, injection molding bubbles, foreign bodies on surface exceed 0.3mm, missing parts, incorrect assembly, inaccurate location of parts, assembly deformation.
4. Automatic feeding, high-speed 360 degrees’ inspections without blind angle, automatic elimination of dirty products.
5. Conveyor belt exit can be equipped with electrostatic removal device.
6. Parts and control mode meet GMP requirements for pharmaceutical packaging material production.
7. PLC automatic control system. Touch screen HMI operation. AI vision detection.
Properties
|
Applicable products |
All products requiring appearance inspection |
|
Production speed |
15000-20000pcs/hr (according to customer’s requirement) |
|
Rate of qualified product |
Above 98%(depends on semi-product quality) |
|
Rate of operation rate |
Above 95% |
|
Power source |
AC380V, 50Hz, 2kw, compressed air:7kg/m3 |
|
Dimension |
Actual size varied with different production speed |
|
Weight |
1000kg |
|
Operator |
3set/person |
